Mean value temperature sensor / rod sensor THERMASGARD® MWTF Pt1000 6m
THERMASGARD® MWTF Pt1000 6m
SKU 1101-3050-5261-000
EAN 4 251325 601946
Product group: WG03
In stock
, available in 1-3 working days
Shipping calculated at checkout.
Regular price
240,01 €
Regular price
Sale price
240,01 €
Entrega en 3 días a España
5 años de garantía
Solicitar descuento por volumen
Product description
- −30...+80 °C
- Temperature [°C]
- PT1000
- Rod length: 6.0 m
- 2-wire connection
- IP65
Mean value temperature sensor THERMASGARD® MWTF (rod sensor 0.4...20 m)
with passive output, in impact-resistant plastic housing with quick-locking screws, with flexible sensor rod (fully active), copper protection tube with plastic coating and anti-kink spring, incl. mounting flange.
THERMASGARD® MWTF-SD mean value temperature sensor (rod sensor 3 m/6 m) with passive output, in impact-resistant plastic housing with snap-on cover, with flexible sensor rod (fully active), protection tube made of reinforced thermoplastic hose and anti-kink spring, incl. mounting flange.
The temperature transmitters are used to detect the average temperature (mean value) in gaseous media, e.g. as duct temperature sensors in ventilation and air conditioning ducts over the entire cross-section or over a defined length (installed in a meandering pattern, they detect the temperature evenly). Mounting clamps MK-05-M (accessories) are available for professional installation of the rod.
with passive output, in impact-resistant plastic housing with quick-locking screws, with flexible sensor rod (fully active), copper protection tube with plastic coating and anti-kink spring, incl. mounting flange.
THERMASGARD® MWTF-SD mean value temperature sensor (rod sensor 3 m/6 m) with passive output, in impact-resistant plastic housing with snap-on cover, with flexible sensor rod (fully active), protection tube made of reinforced thermoplastic hose and anti-kink spring, incl. mounting flange.
The temperature transmitters are used to detect the average temperature (mean value) in gaseous media, e.g. as duct temperature sensors in ventilation and air conditioning ducts over the entire cross-section or over a defined length (installed in a meandering pattern, they detect the temperature evenly). Mounting clamps MK-05-M (accessories) are available for professional installation of the rod.
Technical data
| Sensor | PT1000 |
| Function type | Measurement of temperature |
| Application / Mounting | Averaging sensor |
| Measured variables | Temperature, passive temperature |
| Probe length | 6.0 m |
| Display | No |
| IP protection class | IP65 |
| Output variant | Cable gland connection |
| Housing | Ty r 1 |
| Measuring range | -30...+80 °C |
