MF-15-K
6,95 €
Pa / bar / inWC
Pressure- and differential pressure transmitters PREMASGARD 7110-U VA
PREMASGARD 7110-U VA
SKU 2004-6191-1200-021
EAN 4 251325 624396
Product group: WG02I
In stock
, available in 3-5 working days
Shipping calculated at checkout.
Regular price
662,02 €
Regular price
Sale price
662,02 €
Entrega en 3 días a España
5 años de garantía
Solicitar descuento por volumen
Product description
- ±1100 Pa
- Accuracy Pressure: ± 3 Pa
- 0-10V
- IP65
The calibratable pressure sensors in the PREMASGARD® 711x - VA series with eight switchable measuring ranges (eight devices in one), housing made of stainless steel V4A, optionally with/without display, with cable gland or M12 plug connector in accordance with DIN EN 61076-2-101 and pressure connection using a stainless steel quick connector (pipe fitting optional) are used to measure positive, negative or differential air pressures. The piezoresistive measuring element is temperature-compensated and guarantees high reliability and accuracy. The pressure sensors are used in clean room, medical and filter technology, in ventilation and air conditioning ducts, in spray booths and commercial kitchens, for filter monitoring and fill level measurement or for controlling frequency converters. The measuring media of the pressure transmitters are clean air (non-condensing) or gaseous, non-aggressive, non-flammable media.
The pressure sensors have a button for manual zero point calibration (automatic zero point calibration optional/standard at 25 Pa) and an offset potentiometer for end value correction. The sensors are calibrated at the factory; fine adjustment by a specialist is possible depending on the environment.
The pressure sensors have a button for manual zero point calibration (automatic zero point calibration optional/standard at 25 Pa) and an offset potentiometer for end value correction. The sensors are calibrated at the factory; fine adjustment by a specialist is possible depending on the environment.
Technical data
| Measured values | Pressure, differential pressure, Pressure (air) |
| Power supply | 24 V AC (± 10%) |
| Output | 0-10V |
| Pressure range | ±100 Pa |
| Display | No |
| Output variant | cable gland |
| Cable connection | cable gland |
| Output | 0 - 10 V |
