Room operating unit (interface) Rymaskon® RYM 1301-TH-OTLLS-M-SM-W

The room control devices of the Rymaskon\u00ae 1000 series are designed for controlling residential, hotel and office rooms and individually regulate the indoor heating, cooling and fan stages. The product family is distinguished by its refined design, intuitive operation and the many combination possibilities of the individual components.

The Rymaskon\u00ae 1000 interface room control devices are used to control temperature, fans, solar shading (retractable/roller shutters, venetian blinds) or lighting (with dimming function). The room control devices provide setpoints either via conventionally wired Modbus or via the wireless, radio-based W-Modbus from the BMS (GLT). The optical display is provided via a 2" TFT display; operation is via capacitive keys (touchkeys). Communication is available either wired via Modbus (RTU) / BACnet (MS/TP) or wirelessly/wireless via W-Modbus (RTU) / W-BACnet (MS/TP).
In addition to the integrated temperature and humidity sensor, optional sensors for CO2 and VOC are available. Furthermore, an input for a passive temperature sensor (NTC10K) and an input for a potential-free contact are available. For example, a window contact or a condensation monitor can be connected. This ensures that all options are available to flexibly and individually climate-control the rooms.
All device types are available in the timeless Iduna 3 enclosure (112 x 89.5 x 24 mm) in the colors white or black. Wall mounting is on standard flush-mount wall boxes or surface-mount.
